CRS504-4XQ-OUT
Product Specification:
Product code: CRS504-4XQ-OUT
CPU: QCA9531 650 MHz
CPU architecture: MIPSBE
CPU core count: 1
Size of RAM: 128 MB
Storage: 32 MB, Flash
Number of 100M Ethernet ports: 1
Number of 100G QSFP28 ports: 4
Switch chip model: 98DX4310
IP rating: IP66
Dimensions: 330 x 200 x 70 mm
Operating system: RouterOS v7, License level 5
Operating temparature: -40°C to +70°C
Number of DC inputs: 3 (PoE-in, DC jack, 2-pin terminal)
PoE-in input Voltage: 43-57 V 802.3bt
DC jack input Voltage: 36-57 V
2-pin terminal input Voltage: 36-57 V
Power adapter nominal voltage: 48 V
Power adapter nominal current: 0.95 A
Max power consumption (without attachments): 25 W
Max power consumption: 38 W
Geral
| Código do Produto | CRS504-4XQ-OUT |
|---|---|
| Arquitetura | MIPSBE |
| CPU | QCA9531 @ 650 MHz |
| Sistema Operativo | RouterOS v7 (Licença Nível 5) |
| RAM | 128 MB |
| Armazenamento | 32 MB FLASH |
| Dimensões | 330 x 200 x 70 mm |
Alimentação
| Entradas DC | 3 (PoE-IN, Jack DC, Terminal 2-pinos) |
|---|---|
| Tensão de Entrada Suportada | 36-57 V (Jack DC/Terminal), 43-57V (PoE-in) |
| PoE-in | 802.3bt |
| Consumo Máximo de Energia | 38 W |
Rede
| Portas 100M Ethernet | 1 (para gestão) |
|---|---|
| Portas 100G QSFP28 | 4 |
| Modelo do Chip do Switch | 98DX4310 |
Ambiente
| Temperatura de Operação | -40°C a +70°C |
|---|---|
| Classificação IP | IP66 |
