Cloud Smart Switch 610-8G-2S+IN with SwitchOS

CSS610-8G-2S+IN

Cloud Smart Switch 610-8G-2S+IN is our answer to the everlasting demand for more power in a small and simple package. It comes with the lightweight SwOS which is easy to configure from your web browser. It gives you all the basic functionality for a managed switch, and more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitation and even adjust some MAC and IP header fields.

Product Specification

• Product code: CSS610-8G-2S+IN

• Switch chip model: 88E6193X

• Dimensions: 200 x 167 x 46 mm

• Operating system: SwOS

• Storage size: 64 KB

• Storage type: FLASH

• Operating temperature: -20°C to +60°C

• PoE-in: Passive PoE

• PoE-in input Voltage: 12-57 V

• Number of DC inputs: 2 (PoE-in, DC jack)

• DC jack input Voltage: 12-57 V

• Max power consumption: 11 W

• Max power consumption without attachments: 5 W

• FAN count: Passive

• 10/100/1000 Ethernet ports: 8

• SFP+ ports: 2

• Certification: CE, EAC, ROHS
