BASTIDOR DIGITUS MURAL 19" 16U C/ PORTA VIDRO 600x450 PRETO

16U wall mounting cabinet, Dynamic 789x600x450 mm, color black (RAL 9005)

• 450 mm depth provides a space saving installation

• Optimized air ventilation and exhaustion

• Lockable safety-glass door with steel frame

TECHNICAL DETAILS

• Safety class rating IP20

• Lockable safety-glass door with steel frame

• Lockable safety glass door with steel frame

• 1-point-locking-mechanism on the front door

• 483 mm (19“) profile rails mounted on the front- and rear side inside of the rack, galvanized

• 483 mm (19“) profile rails are adjustable in depth and with height unit marking

• 0.8 - 1.2 mm strong sheet steel with high load capacity, powder coated

• Cable entry on the rear side, roof and base (pre-punched break-outs)

• Roof is prepared for fan units (punched out entries)

• Ventilation slots for active and passive ventilation and exhausting

• 4 earthing points (base, side panel and front door) with protection cap

• Equipment mounting depth min.-max.: 335 -380 mm

• Cabinet type: Wall mounting cabinet

• Color: black, RAL 9005

• Depth: 450 mm

• Front door: Glass door, single opening

• Load capacity: 60 kg

• Side panels: Both sides

• Units: 16

• Width: 600 mm

• IP protection class: IP20

• Mounted: yes

• Package Content:

• Earthing wire set

• Installation set (screws, cage nuts, washers)

• 2 x Keys
