CRS504-4XQ-IN
The small size combined with the low power consumption (25W without attachments!) is perfect to start expanding 100 Gigabit networking in everyday setups. This speed is no longer limited to data centers, ISPs, and large offices. You too can upgrade your 10 or 25 Gigabit network and join the one hundred club!
There are four 100 Gigabit QSFP28 ports. Use them to connect other 100 Gigabit devices or grab a breakout cable to connect multiple 25 Gigabit devices: each port is connected to four 25 Gigabit lines, allowing you to connect 16 x 25 Gigabit devices. In fact, you can mix and match all kinds of connections this way: 100 Gigabits on one port, 40 Gigabits on the other, 4x25 Gigabits on the third, and maybe even some 10G or 1G cables on the fourth. Obviously, there is an Ethernet port for management purposes as well.
Product Specification:
Product code: CRS504-4XQ-IN
Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
RouterOS license: 5
Operating System: RouterOS
Size of RAM: 64 MB
Storage size: 16 MB
Storage type: FLASH
Tested ambient temperature: -40°C to 70°C
Number of AC inputs: 2
AC input range: 100-240
Number of DC inputs: 3 (DC jack, PoE-IN, 2-pin terminal)
DC jack input Voltage: 36-57 V
2-pin terminal input Voltage: 36-57 V
Frequency (Hz): 47-63
Max power consumption: 41 W
Max power consumption without attachments: 25 W
Cooling type: 2
PoE in: 802.3 bt
PoE in input Voltage: 43-57 V
10/100 Ethernet ports: 1
Number of 100G QSFP28 ports: 4
Serial console port: RJ45
CPU temperature monitor: Yes
PCB temperature monitor: Yes
Voltage Monitor: Yes
Certification: CE, EAC, ROHS
IP: 20
