Mikrotik L009UiGS-2HaxD in desktop case with RouterOS L5

L009UiGS-2HaxD-IN

Product Specification

• Product code: L009UiGS-2HaxD-IN

• CPU: Dual-Core IPQ-5018 800 MHz

• CPU architecture: ARM 64bit (RouterOS 32bit)

• Size of RAM: 512 MB

• RAM type: DDR3L

• Storage: 128 MB, NAND

• Number of 1G Ethernet ports: 8

• Number of 1G SFP ports: 1 (2.5G supported)

• USB port: 1 (3.0 type A)

• Serial console port: RJ45

• Switch chip model: 88E6190

• Wireless interface model: IPQ-5018

• Wireless: 2.4 GHz 802.11b/g/n/ax dual-chain

• Antenna gain: 4 dBi

• Dimensions: 220 x 125 x 22 mm

• Operating system: RouterOS v7, License level 5

• Operating temperature: -40°C to +70°C

• PoE-in: 802.3af

• PoE-Out*: Passive PoE

• Max out per port output (DC input 24-30 V): 1 A

• Max out per port output (DC input 30-56 V): 450 mA

• Number of DC inputs: 2 (PoE-in, DC jack)

• PoE-in input Voltage: 24-56 V

• DC jack input Voltage: 24-56 V

• Max USB current: 1.5 A

• Power adapter nominal voltage: 24 V

• Power adapter nominal current: 1.5 A

• Max power consumption without attachments: 12 W

• Max power consumption: 45W (with appropriate PSU)

* PoE-Out works only if powered by DC jack
