NanoBeam M2, antenna 400mm18dBi

SKU
PBE-M2-400
79,11 € 64,32 €
Access Point AirMax 2.4GHz (AP/CB).
EAN
810354022609

Sem stock

Contacte-nos para previsão

PBE-M2-400

High-Performance airMAX® Bridge Incorporating a dish reflector design with advanced technology, the PowerBeam® is the latest generation of Ubiquiti Networks® airMAX® CPE for customer locations.

Product Specification

  • Dimensions: 420 x 420 x 289 mm

  • Weight: 1.795 kg

  • Power Supply: 24V, 0.5A PoE

  • Max. Power Consumption: 6W

  • Operating Frequency: 2405-2475 MHz

  • Gain: 18 dBi

  • Networking Interface: (1) 10/100 Ethernet Port

  • Processor Specs: Atheros MIPS 74Kc, 560 MHz

  • Memory: 64 MB DDR2, 8 MB Flash

  • LEDs: (1) Power, (1) LAN, (4) WLAN

  • Signal Strength LEDs: Software-Adjustable to Correspond to Custom RSSI Levels

  • Max. VSWR: 1.5:1

  • Channel Sizes: 5/8/10/20/30/40 MHz

  • Polarization: Dual Linear

  • Enclosure: Outdoor UV Stabilized Plastic

  • Mounting: Pole-Mount (Kit Included)

  • Wind Loading: 278.4 N @ 120 km/h

  • Wind Survivability: 120 km/h

  • ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV

  • Operating Temperature: -40 to 70° C (-40 to 158° F)

  • Operating Humidity: 5 to 95% Noncondensing

  • Wireless Approvals: FCC, IC, CE

  • RoHS Compliance: Yes

  • Salt Fog Test: IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5

  • Vibration Test: IEC 68-2-6

  • Temperature Shock Test: IEC 68-2-14

  • UV Test: IEC 68-2-5 at 40° C, Equivalent: ETS 300 019-1-4

  • Wind-Driven Rain Test: ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
