Ubiquiti airFiber NxN 4x4 MIMO Multiplexer

The airFiber NxN is a thoughtfully engineered MIMO multiplexer that increases the amazing throughput of your airFiber link by up to 400%, while simultaneously establishing redundancy without the need of additional antennas. The airFiber NxN is a scalable MIMO multiplexer that combines multiple airFiber 5X radios on a single dish antenna for superior noise immunity performance, redundancy, and multi-Gigabit throughput. Upgrading a 5 GHz airMAX or airFiber link is fast and easy. simply attach the airFiber NxN to the fast-mount on the antenna and connect the RF cables.



Product Features
• 4x4 MIMO backhaul technology: Simply mount two airFiber 5X radios for Plug and Play installation. You can use multiple channels and place them anywhere within the radio band
• Reduced tower footprint and cost: Multiple airFiber 5X radios mounted on a single dish antenna maximizes throughput and capacity in a clean, compact tower footpring, minimizing tower costs
• Superior link redundancy solution: Multiple airFiber X radios with multiple carriers on multiple frequency bands provide the ultimate noise immunity and link redundancy performance
• Mounting versatility: The airFiber NxN Multiplexer can be attached to most 5 GHz airFiber X or RocketDish antenna models. For any other antenna configuration, you can mount the airFiber NxN Multiplexer on a pole
• Pair with EdgePoint: The EdgePoint provides link aggregation and powerful configuration features, including radiolink load balancing and advances reliability for optical fiber deployments



Product Specifications
• Redundant link: Up to 1
• Aggregate throughput: 1+ Gbps
• Dimensions: 197.5 x 240.0 x 103.2 mm (7.78 x 9.48 x 4.06")
• Weight: 0.4 kg (0.8 lb)
• RF Connectors: (2) RP-SMA Weatherproof (CH0, CH1) ; (4) RP-SMA Weatherproof (A0, A1, B0, B1)
• Cable Loss: 4.1 dB
• Supported airFiber X Radio: AF-5X
• Multiplex MIMO: 2 x (2x2)
• Mounting: airFiber X/Rocket Mount Compatible
