Ubiquiti UniFi USW-FLEX

USW-Flex

5-Port managed PoE switch with (1) 802.3at/bt (PoE+/PoE++) input port and (4) 802.3af (PoE) Gigabit Ethernet ports

Build and expand your network with the UniFi® Switch, part of the UniFi Enterprise System. The UniFi Switch, model USW-Flex, is a configurable Layer 2 Gigabit switch with auto-sensing 802.3af PoE. It offers 5 RJ45 Gigabit Ethernet ports, providing 1 PoE input and 4 PoE output links to your devices.

The UniFi Switch Flex features a single PoE In port for power and four PoE ports that provide up to 15W PoE output to power a UniFi access point or other PoE devices. With 802.3bt rated PoE switches (USW-Pro-48-PoE, USW-Pro-24-PoE, US-XG-6POE, and USW-Industrial switches, sold separately) as power source, USW-Flex supports maximum 46W PoE output budget. It has weatherproof housing and offers versatile mounting options.

Managed and configured by the UniFi Controller or UniFi Mobile app, the UniFi Switch Flex offers basic Layer 2 switching protocols and features. The UniFi Controller and mobile app allow admins to configure and monitor virtually all of the switch features using a graphical user interface from anywhere.

* To enable PoE output power, select Power Source > PoE Injector in UniFi Controller.

Product Specification:

• Weight: 230 g

• Networking Interfaces: (5) 10/100/1000 Mbps RJ45 Ports

• Management Interface: Ethernet In-Band

• PoE Out (Ports 2-5): 802.3af (Pins 1, 2+; 3, 6-)

• Max Power Consumption (Excluding PoE Output): 5W

• Max PoE Wattage Per Port: 15.4W

• Total PoE Power Budget Powered by 802.3af: 8W

• Total PoE Power Budget Powered by 802.3at: 20W

• Total PoE Power Budget Powered by 802.3bt: 46W

• Total PoE Power Budget Powered by PoE Adapter (Enabled in Controller): 46W

• Voltage Range 802.3af: 44 - 57V

• Voltage Range 802.3at/bt: 50 - 57V

• LEDs: System (Status) / RJ45 Data Ports PoE; Link/Speed/Activity

• ESD/EMP Protection: ± 16kV Air, ± 16kV Contact

• Operating Temperature 46W PoE Output: -40 to 55° C

• Operating Temperature 25W PoE Output: -40 to 65° C

• Operating Humidity: 5 to 95% Noncondensing

• Certifications: CE, FCC, IC
